16 18 Bit MCU SPI LCD Display Module 300cd/m2 ROHS 3.5 Inch

Ask Lasest Price
Brand Name :	3.5 Inch
Model Number :	CH350HV37A
Certification :	ROHS 、ISO9001 、CE
Price :	/
Payment Terms :	T/T
Supply Ability :	200K PCS / Month
Delivery Time :	7 - 15 working days

Add to Cart

Product Details
Company Profile

16 18 Bit MCU SPI LCD Display Module 300cd/m2 ROHS 3.5 Inch

3.5 Inch SPI LCD Display Module 8 / 9 / 16 / 18bit MCU RGB Interface

320 * 480

MODEL NO.	CH350HV37A
Module type	3.5"TFT
Display Mode	TN/Transmissive/Normally white
Number of Dots	3203(RGB)480
Viewing Direction	6 o'clock
Module size	56.54(W)84.96(H)2.4(T)mm
TFT Active area	48.96(W)*73.44(H)mm
Interface	SPI,MCU,SPI+RGB
Luminace	300cd/m2

16 18 Bit MCU SPI LCD Display Module 300cd/m2 ROHS 3.5 Inch

ITEM	STANDARD VALUES	UNITS
Dot pitch	0.153(W)×0.153(H)	mm
Interface	4-lines_8bit / 3-lines_9bit SPI 8-/ 9-/16-/18-bit 8080 system interface 16-/18-bit RGB interface	--
Operating temperature	-20 ~ +70	℃
Storage temperature	-30 ~ +80	℃
Back Light	6 White LED in parallel	--
Weight	TBD	g

16 18 Bit MCU SPI LCD Display Module 300cd/m2 ROHS 3.5 Inch

Module Type	Display Area	Display Mode
1.44 inch TFT LCD Display	25.50 * 26.50 mm	Normally White IPS, Transmissive
1.44 inch TFT LCD Display	25.50 * 26.50 mm	Normally White TN, Transmissive
1.50 inch TFT LCD Display	29.76 * 22.32 mm	Normally Black IPS, Transmissive
1.54 inch TFT LCD Display	27.72 * 27.72 mm	Normally Black IPS, Transmissive
1.54 inch TFT LCD Display	27.74 * 27.74 mm	Normally Black IPS, Transmissive
1.77 inch TFT LCD Display	28.03 * 35.04 mm	Normally White TN, Transmissive
1.80 inch TFT LCD Display	28.03 * 35.04 mm	Normally White TN, Transmissive
2.00 inch TFT LCD Display	30.60 * 40.80 mm	Normally White TN, Transmissive
2.10 inch TFT LCD Display	Circular display area	Normally White IPS, Transmissive
2.31 inch TFT LCD Display	46.75 * 35.06 mm	Normally White TN, Transmissive
2.40 inch TFT LCD Display	36.72 * 48.96 mm	Normally White TN, Transmissive
2.40 inch TFT LCD Display	36.72 * 48.96 mm	Normally White IPS, Transmissive
2.80 inch TFT LCD Display	43.20 * 57.60 mm	Normally White TN, Transmissive
2.80 inch TFT LCD Display	43.20 * 57.60 mm	Normally White IPS, Transmissive
3.00 inch TFT LCD Display	36.72 * 65.28 mm	Normally Black IPS, Transmissive
3.20 inch TFT LCD Display	48.60 * 64.80 mm	Normally White TN, Transmissive
3.50 inch TFT LCD Display	70.08 * 52.56 mm	Normally White TN, Transmissive
3.50 inch TFT LCD Display	70.08 * 52.56 mm	Normally Black IPS, Transmissive
4.00 inch TFT LCD Display	51.84 * 86.4 mm	Normally Black IPS, Transmissive
4.00 inch TFT LCD Display	71.86 * 70.18 mm	Normally Black IPS, Transmissive
4.30 inch TFT LCD Display	95.04 * 53.86 mm	Normally White TN, Transmissive
4.30 inch TFT LCD Display	95.04 * 53.86 mm	Normally Black IPS, Transmissive
5.00 inch TFT LCD Display	110.88 * 62.83 mm	Normally White TN, Transmissive
5.00 inch TFT LCD Display	108.00 * 64.8 0mm	Normally Black IPS, Transmissive
5.50 inch TFT LCD Display	68.04 * 120.96 mm	Normally Black IPS, Transmissive
6.00 inch TFT LCD Display	74.52 * 132.48 mm	Normally Black IPS, Transmissive
7.00 inch TFT LCD Display	154.08 * 85.92 mm	Normally White TN, Transmissive
7.00 inch TFT LCD Display	153.6 * 90 mm	Normally White TN, Transmissive
7.00 inch TFT LCD Display	154.21 mm * 85.92 mm	Normally Black IPS, Transmissive
8.00 inch TFT LCD Display	107.64 * 172.22 mm	Normally Black IPS, Transmissive
9.00 inch TFT LCD Display	196.61 * 114.15 mm	Normally White TN, Transmissive
10.10 inch TFT LCD Display	135.36 * 216.58 mm	Normally Black IPS, Transmissive
